Rotary Station Rotary Laser by Plott

Home > Winners > #79783


DESIGN DETAILS
DESIGN NAME:
Rotary Station

PRIMARY FUNCTION:
Rotary Laser

INSPIRATION:
When you are on a job, one of the greatest losses of time and money is when a tool breaks and you have to wait to have it repaired. Nothing hurts productivity like going on a site in the morning and setting your instrument up, only to have it tip over and break before you’ve even started working. You’ve now lost half of your workday as your crew watches you drive away to the repair shop.

UNIQUE PROPERTIES / PROJECT DESCRIPTION:
The Rotary Station solves the problem of equipment breakage crippling production. The Rotary Station has a circular roll cage made of panels to increase durability during drops. The individual points that connect the shell to the core are also designed to break in extreme impacts. The core remains functional, so your work can continue and make repairs once the job is done. Reinstalling the panels is an easy process that can be done yourself, eliminating additional down time on the jobsite.

OPERATION / FLOW / INTERACTION:
Our Rotary Station is all about efficiency. Instead of a case, the core has built-in storage for your detectors, remote, and other accessories, saving you space on your job site and protecting these devices even if the outer shell has been damaged. The Rotary Station also can measure distances with our detector, allowing you to shoot distance for a job and save the hundreds of dollars it would cost to hire a surveyor or buying / learning to use a complex instrument such as a Total Station.

PROJECT DURATION AND LOCATION:
-

PRODUCTION / REALIZATION TECHNOLOGY:
-

SPECIFICATIONS / TECHNICAL PROPERTIES:
Height - 50.76 cm Length - 40.37 cm Width - 48.76 cm

TAGS:
Laser, Measurement, construction, Rotary Laser, Level

RESEARCH ABSTRACT:
One of the greatest losses of time and money is when a tool breaks and you have to wait to have it repaired. Nothing hurts productivity like going on a site in the morning, setting your instrument up and getting ready to work only to have it tip over and break. You’ve now lost half of your day’s work as your crew watches you drive away to the repair shop. We built our Rotary Station with this in mind. With a circular roll cage made up of panels that increase durability during a drop. The individual points that connect to the inner core are also designed to break in the case of extreme impact. This Rotary Station is all about efficiency. Instead of being stored in a bulky case, it has built-in storage for your detector, remote and other accessories,saving you space on the job site. The Rotary Station also contain our patented dimensionality platform which enables it to read distances when paired with our detector. By making it easy for you to measure distances for a job the Rotary Station saves you the $1,000 it would have cost to either have someone come out for the service or to buy and learn how to use a complex Total Station.

CHALLENGE:
We wanted to make an all in one Rotary Laser capable of distance measurement and be a self contained storage unit that was able to “roll with the punches.” Building the Rotary Station with a roll cage design started to solve this problem but we took it further by designing panels that are easily replaceable saving time of repair and keeping the unit running. Also being the first rotary to include distance measurement met us with many technical challenges.

ADDED DATE:
2019-02-26 17:15:10

TEAM MEMBERS (8) :
David Xing, Vincent Wang, Albert Shi, Jimmy Zeng, Andy Yao, Veronica Santoso, Daniel Kison and

IMAGE CREDITS:
Plott, 2018.

Visit the following page to learn more: http://www.nwismart.com
VOTE FOR THIS DESIGN

VOTE FOR THIS ENTRY

CLIENT/STUDIO/BRAND DETAILS
NAME:
Plott

PROFILE:
From working with construction professionals and our own DIY experiences, we understand it's not easy to change your surroundings. We make connected tools that that eliminate complex dimensioning and planning then translates your plan to real world points. Without needing to do any math. We are your partners in creativity enabling you to focus on how you want things to be, and then making the change in the real world.

NOMINATION DETAILS

Rotary Station Rotary Laser by Plott is a Nominee in Hardware, Power and Hand Tools Design Category.

· This project is currently confidential as results have not been announced yet. Images and further details of the project is not available for public yet, please check back later. If you are the owner of this design, please login to view the images.

· Click here to register today inorder to be able to view the profile and other works by Plott when results are announced.
AWARD DETAILS

Rotary Station Rotary Laser by Plott is Winner in Hardware, Power and Hand Tools Design Category, 2018 - 2019.



· Press Members: Login or Register to request an exclusive interview with Plott.

· Click here to register inorder to view the profile and other works by Plott.
