Self Smear Test Kit Self Smear Test Kit by Hakan Gürsu

Home > Winners > #25349


DESIGN DETAILS
DESIGN NAME:
Self Smear Test Kit

PRIMARY FUNCTION:
Self Smear Test Kit

INSPIRATION:
-

UNIQUE PROPERTIES / PROJECT DESCRIPTION:
Smear test is a special screening test to control the cervix for both infections and cancer/pre-cancer situations. Early detection of cervical cancer and pre-cancerous lesions are the aims of this test. As in all cancers, cervical cancer occurs after a long time hidden-disease period. Thus, early diagnosis is quite important for the cure of this cancer and smear test is acknowledged as the most significant test for early diagnosis of this cancer. Two types of test techniques are available and used. First one is the conventional technique in which doctors examines the outer opening of cervix of the uterus and obtains a sample by using brush. Later, the sample is sent to laboratory inside lamellas. Second technique is a liquid-based one. After gynecological examination, again a sample is acquired by using brush, later which is put in a special liquid. Based upon definitions of these techniques, it can be stated that it is required to have a doctor or a specialist to make smear test that is acquiring tissue from the opening of uterus, without damaging the tissue in vaginal area. Self Smear Test Kit is designed in order for women to have smear test themselves. With the help of this product, it is possible to obtain tissue from the opening of uterus without damaging the tissues in vaginal area. The product is used manually. Design consists of three main parts: Handle and the mechanism that is prompted by handle, body and cap. Assigned parts on the body are pushed to open the three-panels that is placed in the front end, enclosing the brush. With this movement, vajina is also opened. Handle in the back and the part attached to handle are connected to the brush and the piece that the brush is attached. By pushing the handle, protector panels enclosing the soft brush are opened, therefore the soft brush which stays in closed position for hygienic concerns comes out. Handle can be turned around its axis, allowing the body to turn, thus enabling the soft brush to turn. Operated as explained, this movement is used to acquire tissue from opening of uterus. After the sample is obtained, handle is pulled backwards, making the protector panels close. Having an annual screening routine with smear test is recomended, frequency varying according to age and various factors. Therefore, cap is designed as changeable, thus usage more than once is made possible. Unused, hygienic cap can be attached to body and activated. Six caps are provided alongside the main equipment. Acquired sample is smeared on the particular plastic container that is included in the equipment set. After closing the lid of container, the sample is ready for test. Cervix cancer is the main figure in the cancer-related deaths of women in developing countries. Smear test has an important role in early diagnosing thus preventing cervix cancer. However, researches stated that standard of knowledge and sanctions in underdeveloped societies on smear test is detected as very low. It is foreseen that usage of smear test will be spread with the help of this product that allows self application without causing damage. As well as being hygienic, self smear test kit is also practical and inexpensive. Product is expected to create added value in the market with its special features.

OPERATION / FLOW / INTERACTION:
-

PROJECT DURATION AND LOCATION:
-

FITS BEST INTO CATEGORY:
Scientific Instruments, Medical Devices and Research Equipment Design

PRODUCTION / REALIZATION TECHNOLOGY:
-

SPECIFICATIONS / TECHNICAL PROPERTIES:
-

TAGS:
-

RESEARCH ABSTRACT:
-

CHALLENGE:
-

ADDED DATE:
2012-02-28 11:56:13

TEAM MEMBERS (1) :


IMAGE CREDITS:
Hakan Gürsu, 2011.

VOTE FOR THIS DESIGN

VOTE FOR THIS ENTRY

CLIENT/STUDIO/BRAND DETAILS
NAME:
Designnobis

PROFILE:
Designnobis is an award winning design consultancy with a visionary approach on product design. Founded in 2006, we have ranked among top industrial design firms by achieving 45 design awards only through 5 years. Specializing in product development and brand identity, we help our clients to differentiate in market by creating products and services with strategic value. We handle design services from research and concept development phase to prototyping and production process. Acting upon the creativity and interdisciplinary teamwork that product development process requires, we aim to become a sustainable innovation center. Our skills include product design, space design, strategy development, brand identity, prototyping and graphic design.

NOMINATION DETAILS

Self Smear Test Kit Self Smear Test Kit by Hakan Gürsu is a Nominee in Scientific Instruments, Medical Devices and Research Equipment Design Category.

· This project is currently confidential as results have not been announced yet. Images and further details of the project is not available for public yet, please check back later. If you are the owner of this design, please login to view the images.

· Click here to register today inorder to be able to view the profile and other works by Hakan Gürsu when results are announced.
AWARD DETAILS

Self Smear Test Kit Self Smear Test Kit by Hakan Gürsu is Winner in Scientific Instruments, Medical Devices and Research Equipment Design Category, 2011 - 2012.



· Press Members: Login or Register to request an exclusive interview with Hakan Gürsu.

· Click here to register inorder to view the profile and other works by Hakan Gürsu.
