Unisync Microscopic Control Handle by Chen Xu |
Home > Winners > #169738 |
 |
|
||||
| DESIGN DETAILS | |||||
| DESIGN NAME: Unisync PRIMARY FUNCTION: Microscopic Control Handle INSPIRATION: Traditional microscopes present cumbersome operation in cellular morphology examination, hindering AI system efficiency. To optimize workflow and reduce operator fatigue, this control handle integrates tri-axis movement into a single-handed design. Furthermore, direct connection to the microscope ensures low latency and precise human-machine collaboration. Speed control is achieved through intuitive joystick offset, providing a more user-friendly and simplified interaction. UNIQUE PROPERTIES / PROJECT DESCRIPTION: This handle is designed for AI cell morphology inspection system, aiming to enhance medical staff efficiency and reduce fatigue in a more accurate, reliable, and user-friendly way. Low latency and precise control are ensured by connecting directly to the microscope rather than using software. The design combines a single-handed grip with intuitive, fluid interaction, meeting the need to operate the computer simultaneously and reducing healthcare worker fatigue. OPERATION / FLOW / INTERACTION: The control handle can be directly connected to the microscope within the AI Inspection System, with an indicator light showing the data transfer status between the microscope and the computer. The symmetrical design does not limit the user's dominant hand. While holding the handle, the thumb and index finger naturally rest on the joystick, enabling easy operation of the microscope stage's tri-axis movement. The speed increases as the joystick is offset further. PROJECT DURATION AND LOCATION: The project started in July 2024 in Beijing and finished in January 2025 in Beijing. |
PRODUCTION / REALIZATION TECHNOLOGY: ABS injection molding. Silver - gray metal spray painting. SPECIFICATIONS / TECHNICAL PROPERTIES: 120mm×130mm×166mm TAGS: Microscopic Control Handle, single-handed , user-friendly, convenient Interaction RESEARCH ABSTRACT: Cell morphology testing is crucial in disease diagnosis. Through communication with pathologists and technicians, we found the traditional microscope operation cumbersome and inefficient, limiting AI system performance. Additionally, intelligent microscopes with software introduce latency and store unscreened data, wasting resources. This project effectively integrates pathologists' real needs into the microscope control handle design, improving operational efficiency. CHALLENGE: The core challenge of the project is how to integrate tri-axis control within limited space, ensuring independent and non-interfering operation of XY and Z axes. In addition, the ergonomic design is also a challenge with the need for microscope precision and stability. The design of the handle also needs to harmonize the comfort and aesthetics of the medical device to create an innovative product that is both functional and aesthetically pleasing. ADDED DATE: 2025-02-25 05:51:00 TEAM MEMBERS (1) : Liu Beibei, Chen Xu, Li Shulong, Zhang Mingjie, Dr. Zhang Rong, Hao Qian, Huang Hao and Wu Fangbo IMAGE CREDITS: Chen Xu, 2024. |
||||
| CLIENT/STUDIO/BRAND DETAILS | |
 |
NAME: Widgtech PROFILE: Beijing Widgtech Co., Ltd. is an interdisciplinary high-tech enterprise integrating cutting-edge scientific research, advanced technology development and innovative product development. Currently, the company focuses on artificial intelligence algorithms, the application of artificial intelligence technology in IVD medical devices, and the optimization of diagnosis and treatment processes with the aid of artificial intelligence, providing more standardized, standardized, efficient and intelligent medical solutions. The company advocates interdisciplinary innovation and cooperation, and uses “human-centered” research and development rules and the most cutting-edge technology to provide better quality AI products. |
| AWARD DETAILS | |
 |
Unisync Microscopic Control Handle by Chen Xu is Winner in Scientific Instruments and Research Equipment Design Category, 2024 - 2025.· Read the interview with designer Chen Xu for design Unisync here.· Press Members: Login or Register to request an exclusive interview with Chen Xu. · Click here to register inorder to view the profile and other works by Chen Xu. |
