Mag Coupling Drive Builtin Louver Glass by Anhui Jinpeng Energy Saving |
Home > Winners > #162692 |
 |
|
||||
| DESIGN DETAILS | |||||
| DESIGN NAME: Mag Coupling Drive PRIMARY FUNCTION: Builtin Louver Glass INSPIRATION: With a focus on living comfort, this insulating glass window with a builtin louver boasts multiple optimized features: a contactless permanent magnet transmission system, an external motor, and solar powered wireless charging technology. These features eliminate exposed wiring and bring various practical benefits, such as excellent sealing, thermal insulation rated at level 7, water tightness up to 700 Pa, and noise reduction down to 35 dB, ensuring a consistently comfortable indoor environment. UNIQUE PROPERTIES / PROJECT DESCRIPTION: The innovative glass window with a builtin louver excels in protection, durability, and intelligence. It features a permanent magnet transmission system, which allows for easy control of the louver without intricate wiring. By integrating an external motor and solar powered charging technology, the window eliminates the drawbacks of exposed wiring. For added convenience, multiple louver control methods are available to meet the diverse needs of users. OPERATION / FLOW / INTERACTION: The external motor supports multiple control methods, including remote control, voice commands, and an app, working in harmony with the contactless permanent magnet transmission system to provide flexible and smooth control of the louver. Additionally, the window can be seamlessly integrated into a smart home system, interacting with other smart devices for users to set up automated scenes as needed. PROJECT DURATION AND LOCATION: The design and development of this window began in Chuzhou in November 2023, and it is set to hit the Chinese market in December 2024. |
PRODUCTION / REALIZATION TECHNOLOGY: The magnetic field strength, planetary gear count, and configuration are precisely engineered to optimize the transmission ratio, meeting diverse demands for torque and force transfer while ensuring smooth, reliable operation of large louvers. The louver is fully enclosed for multiple advantages, such as excellent thermal insulation, waterproofing, and dustproofing. The use of stable, durable aluminum magnesium alloy slats further enhances its performance, contributing to a longer service life. SPECIFICATIONS / TECHNICAL PROPERTIES: Custom products, no fixed size TAGS: Window with a builtin louver, External motor, Contactless transmission structure, Solar powered charging, Multiple control options RESEARCH ABSTRACT: Traditional windows with builtin louvers often place the motor within the insulating glass, which can shorten its lifespan due to high temperatures in summer. Another issue arises when wiring penetrates the sealant, compromising wind resistance, airtightness, and water tightness. In response, this design moves the motor outside the glass and combines a contactless transmission system and solar powered wireless charging, eliminating exposed wiring. Gone are the drawbacks of conventional designs. CHALLENGE: To address the key challenge of minimizing environmental impact, the external motor is integrated with solar powered wireless charging technology, ensuring it operates without additional energy consumption or carbon emissions. Moreover, the builtin louver allows users to flexibly adjust the sunlight streaming in, reflecting around 60 percent of solar heat outward. This excellent insulation performance reduces the load on air conditioning, aligning with modern environmental protection goals. ADDED DATE: 2024-06-26 06:27:23 TEAM MEMBERS (1) : Dawei Liu, Wenzhog Zhang, Rui Sun, Xiaoqing Huang IMAGE CREDITS: Anhui Jinpeng Energy Saving, 2024. |
||||
| Visit the following page to learn more: http://www.jinpengsun.com/ | |||||
| CLIENT/STUDIO/BRAND DETAILS | |
 |
NAME: Anhui Jinpeng energy saving technology Co., LTD PROFILE: Established in November 2015, Jinpeng Energy Saving Technology Co., Ltd. specializes in energy-saving and environmental protection material technology R&D, door and window manufacturing, installation, curtain wall, glass manufacturing and processing. In 2017, the company independently set up a R&D center (enterprise technology center, industrial design center, laboratory, etc.), mainly producing high-density energy-saving aluminum alloy doors and windows, thermal insulation and soundproof plastic-steel doors and windows, glass skylights, pressure-resistant and waterproof doors and windows, etc. The core technologies related to the company's products are self-developed with independent intellectual property rights. The company holds 40 patents in total, 4 of which are authorized invention patents. The company's leading product, green energy-saving door & window, holds a market share of about 78% now. |
| AWARD DETAILS | |
 |
Mag Coupling Drive Builtin Louver Glass by Anhui Jinpeng Energy Saving is Winner in Furniture Accessories, Hardware and Materials Design Category, 2024 - 2025.· Read the interview with designer Anhui Jinpeng Energy Saving for design Mag Coupling Drive here.· Press Members: Login or Register to request an exclusive interview with Anhui Jinpeng Energy Saving. · Click here to view the profile and other works by Anhui Jinpeng Energy Saving. |
