| DESIGN NAME: CNC Machining Center PRIMARY FUNCTION: Computer Numerical Control INSPIRATION: Computer numerical control machining center is a kind of machining machine with more functions. Through the design of the Computer numerical control machining center, we make it more concise and easy to use, saving a lot of time and cost for the development and upgrading of new products, so that the company has strong competitiveness. UNIQUE PROPERTIES / PROJECT DESCRIPTION: Computer numerical control machining center concentrates the functions of milling, boring, drilling, tapping and cutting threads on one device, so that it has a variety of technological means. The machining center is equipped with a tool magazine, which stores different numbers of various tools or inspection tools, which are automatically selected and replaced by the program during the machining process. OPERATION / FLOW / INTERACTION: The machining center is equipped with a tool magazine, which stores different numbers of various tools or inspection tools, which are automatically selected and replaced by the program during the processing. This is the main difference between it and computer numerical control milling machine and Computer numerical control boring machine. Especially for work pieces that must use tooling and machine equipment to ensure product quality and efficiency. This will save a lot of time and cost for the development and modification of new products. PROJECT DURATION AND LOCATION: 2018.6-2020.3, Shenyang China |
PRODUCTION / REALIZATION TECHNOLOGY: Automatic control, material processing, ergonomics, industrial design SPECIFICATIONS / TECHNICAL PROPERTIES: The contour size of this machine tool is 2090 mm x 3435 mm x 2678 mm. TAGS: Computer Numerical Control, CNC, heavy machine RESEARCH ABSTRACT: The design of computer numerical control machining center aims to reflect the high-end, precision and sense of science and technology of the machine tools, and at the same time should meet the most basic human-machine function requirements of the product, as well as the requirements of the structure and function of each part. The whole product is made of metal. The special processing technology requires an in-depth understanding of the shape of the material in the design. CHALLENGE: The most difficult part of the design is how to achieve the unity of function and appearance, and enhance the corporate image of the product. ADDED DATE: 2021-02-27 07:12:07 TEAM MEMBERS (5) : Lu Na, Wang Zhuo, Lin Yutong, Liu Yutong and Cui Xinyue IMAGE CREDITS: Jun Chen, 2020. |
||||
| CLIENT/STUDIO/BRAND DETAILS | |
 |
NAME: Design Innovation Center, Shenyang Aerospace University PROFILE: This equipment is a CNC machine tool designed by our school for other enterprises. The machine tool adopts environmentally friendly paint, blue and white color matching highlights the elegant craftsmanship, and the unique shape establishes a new corporate image, which has been appreciated and praised by the company. |
